Economical 45/60 Fish-bone Double End Tenoner

Economical fish-bone double end tenoner machine is used for continuous processing profile of laminate flooring and solid wood floors, do parquet floors, special degree generally 45° or 60°.
Reciprocating work, processing 3~4 boards each cycle, high precision.
  • HALLMARK
  • 16 KW
  • 6~40mm
Availability:

Product Description

Economical 45/60 Fish-bone Double End Tenoner Overview


7 (1)


This machine is mainly applicable to the continuous production of solid wood floor,laminate floor and engineered floor, can do parquet floors,simple structure, easy operation.

This kind machine can do a special angle floor of  45 °, and 60 °, or a routine 90 ° floor.

Each time the device can process 3 ~ 4 floors at the same time, using a Inverter motor, the feed speed is adjustable, run along the linear guide, high precision, and automatically return to the origin after processing is completed.



Economical 45/60 Degree Fish-bone Double End Tenoner Photos



设备2 (1)



degree double end tenoner 1
degree double end tenoner
5




Economical 45/60 Degree Fish-bone Double End Tenoner Main Parameters



Floor length 400 - 1200mm(Can be customized)
Floor width Less than 400mm
Thickness 6 - 40mm
Feeding speed 10m/min adjustable
Angle error 0.3°- 0.5°
Straightness error About 0.1mm
Total power 16Kw
Capacity About 150㎡/8h

(Above technical parameters just for reference,will design according to actual situation)



Economical 45/60 Degree Fish-bone Double End Tenoner Main Features


  • High precision production processing.

  • Feeding by frequency conversion control.

  • Adopts advanced linear guide.

  • Uses 8 units of pneumatic cylinders to pinch raw board;

  • All adjusting shafts are equipped with counters

  • The chain and guides lubricated by a self-oil feeder


45/60 Degree Parquet Floor Photos



parquet floor (3)
parquet floor (2)
parquet floor (1)





Our Services





Pre-sale

●Provide the information in time at customer requirement and make reasonable proposals and budgeting for whole flooring production line.

●Give technical support for the customer's renovation of old facilities for free

●Provide one-stop service and support to the customer's other equipment


●Provide raw material related consultation


In-sale

●On-site planning for the customers by professional engineer



●Valuable advice and recommendations on the purchasing of other auxiliary accessories and raw material



●Free training for operators



After-sale

●For all sold products ,free replacement of quality problems within the warranty period,provide lifetime keep-up and maintenance service


●All-around keep-up,transportation and transformation of equipment


●Provide production and technical advisory service


●Provide on-site installation, debugging , training and remote guidance services,







Why choose HallMark as your supplier?



  1. Rich experience and professional design


    We have 15 years experience in flooring industry,also has many years exporting experience. Each equipment location,passage will be designed reasonably to meet safety production.



  2. Competitive price


    HallMark has own factory,with the same configuration,the price is competitive.And we are familiar with the Chinese market,our suppliers provide high-quality cost-effective accessories.



  3. Timely after-sale service

    We have over 15 skilled technicians offer after-sale service, will be sent to the customer's factory to assist in the installation and debugging of the flooring production line until it runs well,and asked for quick responses to customer questions within 8 hours.



  4. One-stop solution


    We provide one-stop service, including market analysis and professional technical consultation,whole SPC  flooring production line, raw materials ,Equipment installation, personnel training,Professional after-sales service team,Renovation of old equipment,make turnkey projects.



  5. Quality control


    Strict quality control of equipment in production and before leaving the factory, and a complete quality management system for purchased parts.Customers are always welcome to make videos or come to the factory to know the production status.



  6. Customized


    HallMark's engineer team will design the layout according to customer’s factory space and production requirements.
